1. Specification: Wire Diameter:0.45-16mm
Opening:0.5 -280 mm
Width :0.5-5 m
2. kinds according to material:
a.stainless steel crimped wire mesh
b.iron crimped wire mesh(carbon steel crimped wire mesh)
c.galvanzied iron crimped wire mesh
d.white steel crimped wire mesh
e.white steel crimped wire mesh
f.black steel crimped wire mesh
g.Mn steel crimped wire mesh
Material:stainless steel wire,galvanzied wire,carbon steel wire,Mn steel wire,iron wire etc.
Weave method:crimped after weave,crimped before weave,flat-top bending,one-way bending,two-way bending,alternative wave bending etc.
Specification:
SWG | Wire diameter(mm) | Mesh | Aperture(mm) | Weight(kg/m2) |
6 | 4.8 | 0.7 | 3 | 14 |
6 | 4.8 | 1 | 2 | 20 |
6 | 4 | 1.2 | 2 | 20 |
8 | 4.05 | 18 | 1 | 15 |
14 | 2 | 3.6 | 1.5 | 1.9 |
14 | 2 | 5.08 | 0.3 | 12 |
14 | 2 | 2.1 | 1 | 2.5 |
14 | 2 | 21 | 1 | 4.2 |
19 | 1 | 2.3 | 0.18 | 1.45 |
22 | 0.71 | 12 | 0.14 | 2.94 |
23 | 0.61 | 18 | 0.8 | 3.4 |
24 | 0.55 | 16 | 0.1 | 2.5 |
24 | 0.55 | 14 | 0.61 | 4 |
25 | 0.5 | 20 | 1.5 | 2.6 |
