Products Information:
Wire Diameter:Gauge 23-Gauge 8
The weight of per coil is 5kg,10kg,15kg,25kg,50kg,100kg and so on.
Characteristic:Hot dipped galvanized wire,zin coating is also very uniformity.
Zin coating:max zin coating can get 300 g/m.
Produce Process:black anneal wire-------High temperature and oil removing-------acid-washing and drying-----hotdipped-----wire coils---packing.
Packing:
1.Inside is plastic film,outside is weave bags.
2.Inside is plastic film,outside is hessian.
3.Also can be packed with paper box.
4.When the goods is not to many,also can use wooden pallets.
Specification:
Hot dipped Galvanized Wire |
Wire Gauge | SWG(mm) | BWG(mm) | Metric(mm) |
8 | 4.05 | 4.19 | 4.00 |
9 | 3.66 | 3.76 | 4.00 |
10 | 3.25 | 3.40 | 3.50 |
11 | 2.95 | 3.05 | 3.00 |
12 | 2.64 | 2.77 | 2.80 |
13 | 2.34 | 2.41 | 2.50 |
14 | 2.03 | 2.11 | 2.50 |
15 | 1.83 | 1.83 | 1.80 |
16 | 1.63 | 1.65 | 1.65 |
17 | 1.42 | 1.47 | 1.40 |
18 | 1.22 | 1.25 | 1.20 |
19 | 1.02 | 1.07 | 1.00 |
20 | 0.91 | 0.84 | 0.90 |
21 | 0.81 | 0.81 | 0.80 |
22 | 0.71 | 0.71 | 0.70 |
